STM32F030x4 STM32F030x6 STM32F030x8
Value-line ARM-based 32-bit MCU with 16 to 64-KB Flash, timers,
ADC, communication interfaces, 2.4-3.6 V operation
FEATURES
Core: ARM® 32-bit Cortex™-M0 CPU, frequency up to 48 MHz
Memories
– 16 to 64 Kbytes of Flash memory
– 4 to 8 Kbytes of SRAM with HW parity checking
CRC calculation unit
Reset and power management
– Voltage range: 2.4 V to 3.6 V
– Power-on/Power down reset (POR/PDR)
– Low power modes: Sleep, Stop, Standby
Clock management
– 4 to 32 MHz crystal oscillator
– 32 kHz oscillator for RTC with calibration
– Internal 8 MHz RC with x6 PLL option
– Internal 40 kHz RC oscillator
Up to 55 fast I/Os
– All mappable on external interrupt vectors
– Up to 36 I/Os with 5 V tolerant capability
5-channel DMA controller
1 x 12-bit, 1.0 µs ADC (up to 16 channels)
– Conversion range: 0 to 3.6 V
– Separate analog supply from 2.4 up to 3.6V
Up to 10 timers
– One 16-bit 7-channel advanced-control timer for 6 channels PWM
output, with deadtime generation and emergency stop
– One 16-bit timer, with up to 4 IC/OC, usable for IR control
decoding
– One 16-bit timer, with 2 IC/OC, 1 OCN, deadtime generation and
emergency stop
– Two 16-bit timers, each with IC/OC and OCN, deadtime generation,
emergency stop and modulator gate for IR control
– One 16-bit timer with 1 IC/OC
APPLICATIONS
Microphone Preamplifier/Processor Computer
Sound Cards Public Address/Paging Systems Communication Headsets
Telephone Conferencing Guitar Sustain Effects Generator
Computerized Voice Recognition Surveillance Systems Karaoke and DJ
Mixers
